Interfaces and Modules

GE RJ45 Ports

14

GE RJ45 Management/HA/DMZ Ports

1 / 2 / 1

GE SFP Slots

-

GE RJ45 PoE/+ Ports

-

GE RJ45 WAN Ports

2

GE RJ45 or SFP Shared Ports

2

Console Port

1

USB Port

1

Internal Storage

480 GB

Included Transceivers

-

System Performance and Capacity

Firewall Throughput (1518 / 512 / 64 byte, UDP)

7.4 / 7.4 / 4.4 Gbps

Firewall Latency (64 byte, UDP)

3 μs

Firewall Throughput (Packet per Second)

6.6 Mpps

Concurrent Sessions (TCP)

2 Million

New Sessions/Sec (TCP)

30,000

Firewall Policies

10,000

IPsec VPN Throughput (512 byte)

4 Gbps

Gateway-to-Gateway IPsec VPN Tunnels

2000

Client-to-Gateway IPsec VPN Tunnels

10,000

SSL-VPN Throughput

250 Mbps

Concurrent SSL-VPN Users

300

SSL Inspection Throughput (IPS, HTTP)

190 Mbps

Application Control Throughput (HTTP 64K)

1 Gbps

CAPWAP Throughput (1444 byte, UDP)

1.5 Gbps

Virtual Domains (Default / Maximum)

10 / 10

Maximum Number of Switches Supported

24

Maximum Number of FortiAPs (Total / Tunnel Mode)

64 / 32

Maximum Number of FortiTokens

1,000

Maximum Number of Registered FortiClients

600

High Availability Configurations

Active / Active, Active / Passive, Clustering

System Performance — Optimal Traffic Mix

IPS Throughput

1.9 Gbps

System Performance — Enterprise Traffic Mix

IPS Throughput

500 Mbps

NGFW Throughput

360 Mbps

Threat Protection Throughput

250 Mbps

Dimensions and Power

Height x Width x Length (inches)

1.75 x 17 x 10

Height x Width x Length (mm)

44.45 x 432 x 254

Weight

7.28 lbs (3.3 kg)

Form Factor

Rack Mount, 1 RU
