Interfaces and Modules

GE RJ45 WAN / DMZ Ports

2 / 1

GE RJ45 Internal Ports

7

GE RJ45 PoE/+ Ports

-

Wireless Interface

-

Console Port

1

USB Port

1

Internal Storage

128 GB

System Performance and Capacity

Firewall Throughput (1518 / 512 / 64 byte UDP packets)

3 / 3 / 3 Gbps

Firewall Latency (64 byte, UDP)

3 μs

Firewall Throughput (Packet per Second)

4.5 Mpps

Concurrent Sessions (TCP)

1.3 Million

New Sessions/Sec (TCP)

30,000

Firewall Policies

5,000

IPsec VPN Throughput (512 byte)

2 Gbps

Gateway-to-Gateway IPsec VPN Tunnels

200

Client-to-Gateway IPsec VPN Tunnels

500

SSL-VPN Throughput

150 Mbps

Concurrent SSL-VPN Users

100

SSL Inspection Throughput (IPS, HTTP)

175 Mbps

Application Control Throughput

650 Mbps

CAPWAP Throughput (1444 byte, UDP)

1.5 Gbps

Virtual Domains (Default / Maximum)

10 / 10

Maximum Number of Switches Supported

8

Maximum Number of FortiAPs (Total / Tunnel Mode)

30 / 10

Maximum Number of FortiTokens

100

Maximum Number of Registered FortiClients

200

High Availability Configurations

Active / Active, Active / Passive, Clustering

System Performance — Optimal Traffic Mix

IPS Throughput

1,400 Mbps

System Performance — Enterprise Traffic Mix

IPS Throughput

400 Mbps

NGFW Throughput

250 Mbps

Threat Protection Throughput

200 Mbps

Dimensions and Power

Height x Width x Length (inches)

1.5 x 8.5 x 6.3

Height x Width x Length (mm)

38 x 216 x 160

Weight

1.9 lbs (0.9 kg)
